• Rating：12VDC,50mA
• Contact Resistance：≤0.05Ω
• Life Cycle：100,000 Cycles
• Insulation Resistance：≥100mΩ max
• Operating Force：160±50gf,250±50gf
• Working Temperature：-25℃ ~+75℃
• Withstand Voltage：AC250V/1 Minute
• Storage Temperature：-25℃ ~+75℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Operating Force | Working Temperature | Withstand Voltage | Life Cycle | Storage Temperature | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R2590 | 12VDC,50mA | ≤0.05Ω | ≥100mΩ max | 160±50gf,250±50gf | -25℃ ~+75℃ | AC250V/1 Minute | 100,000 Cycles | -25℃ ~+75℃ | 暫無 |
| R2591 | 12VDC,50mA | ≤0.05Ω | ≥100mΩ max | 160±50gf,250±50gf | -25℃ ~+75℃ | AC250V/1 Minute | 100,000 Cycles | -25℃ ~+75℃ | 暫無 |
