• Rating：12VDC 50mA
• Travel：10.13mm
• Life：1100,000 cycles
• Contact Resistance：1100mΩ MAX Initial
• Insulation Resistance：1100mΩ min. 100VDC
• Dielectric Strength：1250VAC(50/60Hz)FOR 1MIN
• Operating Force：12=180gf 3=260gf
• Operating Temperature：1-30℃ ~70℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Travel | Life | Operating Temperature | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R10-2030-29-180 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.13mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
| R10-2030-25-180 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.13mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
| R10-2040-G1 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.13mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
| R10-2446 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 2=180gf 3=260gf | 0.13mm | 100,000 cycles | -30℃ ~70℃ | 暫無 |
